Haas Desktop Mill Fixture Tooling Plate

Haas Desktop Mill Fixture Tooling Plate

$ 149.99 USD
$ 149.99 USD
Sale Sold out
Hole Pattern
Version
Our P/N: S1085
Accessory Kits [1] Accessory Kit (+$ 231.94 ea.)

12 in stock

Product Specifications

10.44" x 7.9" x 0.48" 6061 Aluminum Fixture & Tooling Plate for Haas Desktop Mills. Sold individually, however two plates may be purchased for higher coverage of machine table.

Inch plates: Holes are 0.75" on center.  Every hole is tapped 1/4"-20.

Metric Plates: Holes are 20mm on center. Every hole is tapped M6.

Note: In ~August 2024 Haas released a new version of the desktop mill, changing the table from (8) t-slots to (6) t-slots. Discounted old stock plates only fit older machines having (8) table t-slots, standard plates fit both versions. Note - all sales on blem, scratch & dent, old stock, or used fixture plates are final.

On-Table Weights
Variant Weight
1/4" / Standard 3.4lbs [1.5kg]
1/4" / Old Stock (see desc.) 3.5lbs [1.6kg]
M6 / Standard 3.4lbs [1.6kg]
M6 / Old Stock (see desc.) 3.5lbs [1.6kg]

Lead Time

In stock plates are typically ready to ship within one business day (other items in order may affect shipping time).

Out-of-Stock Lead Times
Material Single Plate Set of 2-3 Plates Set of 4+ Plates
4140 Steel 3-4 weeks 4-5 weeks 5-6 weeks
7075 Aluminum (Anodized) 4-6 weeks 4-6 weeks 5-7 weeks
6061 Aluminum 3-4 weeks 3-4 weeks --

Please contact us for specific lead times or to inquire about time-critical orders.

Shipping

This fixture plate ships via standard parcel shipping (FedEx Ground or USPS Priority). For questions about additional shipping methods, please contact us.

Mounting hardware not included. We recommend QTY6 M6 x 10mm SHCS (McMaster 91290A316 or equiv.) and t-nuts for your machine table.

For fixture plate installation instructions see our Knowledge Base article here.

Haas Desktop Mill Fixture Plate Solid Model (1/4") (.step) Haas Desktop Mill Fixture Plate Solid Model (M6) (.step) Haas Desktop Mill Fixture Plate Drawing (.pdf) Haas Desktop Mill Fixture Plate Solid Model (Old Stock, 1/4" & M6) (.step)
